拍前请联系店家确认下实际库存量以及实时报价，未确认库存前请慎拍，以免库存不足给您造成不必要的困扰。同品牌下有多种型号，详情请咨询客服。



供应商:

Teledyne Relays

部件编号:

412H-12

RoHS:

Yes

Type:

High Temperature Relay

Relay Construction:

Non-Latching

Contact Arrangement:

DPDT

AC Coil Voltage:

N/A

DC Coil Voltage:

12 V

Maximum Current Rating:

1DC,0.25AC A

Coil Current:

30.77 mA

Coil Resistance:

390 Ohm

Mounting:

Through Hole

Operating Temperature:

-65 to 200 °C

Termination Style:

PC Pin



SERIES RELAY TYPE

412H DPDT high-temperature relay

422H DPDT high-temperature magnetic-latching relay

432H DPDT sensitive high-temperature relay



如需以下 412H/422H/432H系列 或同品牌其他型号，

可咨询客服或联系电话：18108218928（VX同号）



412H-12 Teledyne relays 凯萨电子

422H-26 Teledyne relays 凯萨电子

432H-5 Teledyne relays 凯萨电子

422H-5 Teledyne relays 凯萨电子

432H-26 Teledyne relays 凯萨电子

412H-18 Teledyne relays 凯萨电子

422H-12 Teledyne relays 凯萨电子
